Heat Core Box Double Head Core Making Machine Foundry Automatic
Vertical Parting Shell Core Shooter Machine For Sale
Product Description
HBS 400B Sand Core Shooting Machine is a sand core manufacturing
machine that uses hot box casting method to cast sand cores of
various shapes and sizes. It is powered by 380V/50Hz and has a PLC
control system for precise and efficient operation. The machine is
designed with safety features and is equipped with a 1-year
warranty for peace of mind. It is ideal for sand core casting,
injection and manufacturing of large-scale projects. The Sand Core
Shooting Machine features innovative technologies including an
integrated sand core injector for precise and efficient injection
of sand cores into the moulds. It is user-friendly and offers
superior performance with its advanced sand core casting device.
With its reliable and durable design, the Sand Core Shooting
Machine is the perfect solution for sand core manufacturing needs.
Technical Parameters
| Parameter | |
|---|
| Product Name | Sand Core Shooting Machine Iron Metal Casting |
| Core Box Weight | 3.2KG*2 |
| Type | Automatic |
| Control System | PLC |
| Weight | 520KG |
| Core Box Size | 340*450*200mm |
| Air Pressure | 0.5-0.8MPa |
| Air Consumption | 0.5m³/min |
| Power | 380V/50Hz |
| Casting Method | Hot Box |
Applications
Sand Core Shooting Machine (Model Number: 400B; Brand Name: HBS) is
an automatic casting machine with a hot box casting method, and is
widely used in the casting industry. It is certified by CE and ISO.
This machine is powered by 380V/50Hz and requires 0.5-0.8MPa of air
pressure for operation. It is capable of producing 50 sets per
month with a minimum order quantity of 1 set. The price range of
the machine is from USD1000 to USD5000, with plywood packing and
export sea standard.
Delivery time is 15-20 days, and payment terms are T/T, L/C, D/A,
D/P. The warranty period for the machine is 1 year.
The Sand Core Shooting Machine can be used to produce various kinds
of sand cores for sand casting parts. It is widely used in the
casting industry for producing sand cores of complex shapes, such
as engine blocks, cylinder heads, and other automotive parts. It
can also be used to produce sand cores for mechanical parts, like
pulleys, gears, and other parts with intricate geometries. The
machine is equipped with advanced control system, which allows for
precise control of the temperature and pressure during the
injection process. The sand core shooting machine is reliable and
easy to operate, and provides a high level of accuracy and
repeatability.
The Sand Core Shooting Machine from HBS is an excellent choice for
casting foundries looking for an efficient and reliable casting
machine. It is designed to provide superior performance and is
built to last. With its advanced control system and high precision,
the machine is able to produce high-quality sand cores quickly and
accurately. The machine is also cost-effective and provides an
excellent value for money.
FAQ
1.COULD YOU ARRANGE THE ENGINEER FOR INSTALLATION AND
COMMISSIONING?
A:Obviously yes,but the buyer pay the charges.
2.HOW TO CHOOSE CORE MAKING MACHINE?
A:Different products require different model(Cotact me for the
details)
3.DO YOU PROVIDE ANY SPARE PARTS WITH THE MACHINE?
A:Yes,we will provide some common parts for you according to our
packing list(cotact us for packing list)
4.WHAT IS THE DELIVERY PERIOD AFTER PLACING THE ORDER?
A:Normally 10-15days after deposit..
5.WHAT IS THE WARRANTY PERIOD AND AFTER-SERVICE FOR YOUR MACHINE?
A:1 year warranty for components and life-long technical
supports(details depends on the warranty rules)
